LUMIA7055" Rugged Mobile
Android

The ESA Lumia 705 rugged tablet is ideal for higly mobile indoor or outdoor workers in harsh enviroment conditions.
Thanks to the scanning trigger accessory and the integrated bar code reader it is fitting perfectly logistic and automatic store applications.
The capacitive multitouch and sunlight viewable display will ensure that the data are always available when needed.

  • Fully rugged IP65 (Water-Dust resistant), MIL-STD810G (vibration/shock/120 cm drop reistant), Fanless device
  • 5” inch screen Glove touch, Rain Touch, 5 finger&pen touch enabled
  • 7 hours operation battery life with 100% charging in less then 2.5 hours
  • Battery hotswap wich enables NON-STOP working
  • Light weight (260g)

LUMIA 705

Download pdf

LUMIA 705MTA1AR0
Product FormTypeRugged Handheld Terminal
Dimension156*74*17
Weight260 g
Device Colorblack
LCDScreen Size5 inch 16:9
Resolution720*1280
Brightness300 Nit
TPTouch PanelMultitouch 5points Capacitive,Glass + Film,Rigidity: above 7H-Anti-scratch
CameraFrontFront2.0MP
RearRear 8.0MP,with flash and auto-focus
SpeakerBuilt-inEmbedded 8Ω/0.7Wspeaker x 1
MicBuilt-inSensitivity:-42db, output resistance2.2kΩ
EarphoneBuilt-inbuilt inx 1
Batterytypepolymer Li-on
Capacity3.8V/4000mAh
Endurance7hrs
CPUTypeMT8735A
Quad-
core ARM® Cortex-A53 MPCore TM
Speed1.45GHz
RAMDDR3L2GB/ LPDDR3
ROM Emmc64GB
CompassBuilt-inelectronic compass
G_sensorBuilt-inGravity acceleration sensor
Light sensorBuilt-inyes
range sensorBuilt-inyes
led indicateBuilt-inIn charging led
WIFIWIFIWIFI 802.11(a/b/g/n) Frequency 2.4G+5.8G dual band WIFI,
BluetoothBuilt-inBT4.0 (BLE) class 1 transmission distance:10m
3G/4GBuilt-inCMCC 5M:
LTE 1/2/3/4/5/7/17/20/38/39/40/41
WCDMA 1/2/5/8
TD-SCDMA 34/39
GSM 2/3/5/8
GPSBuilt-inGPS;Capture sensitivity: -160 dBm;Cool Start Time:<60 seconds,Hot start time:<28seconds,frequency::0.25 Hz … 10 MHz (configurable)
2D barcode scannerBuilt-inHoneywell3680
TF slotExtensive External Memorysupport SDHC/SDXC x1 max:128G
SIM slotSIM cardSIMx1
USB2.0 interfacedata transmissionMicr usb2.0*1 OTG
Earphone JackAudio Output3.5mm standard earphone jack x1
System HOME keyhomeHOME*1
barcodebarcodebarcode *1
POGO PINdocking chargercharging function x1
Power onpress keypower key x1
Volume + -press keyVolume + - x2
otherspress keyMENU*1,BACK*1,CUSTOM*1
Operating SystemOS versionAndriod 8.1
Certificate SystemIP65IP65 Report: Water resistance:IP-X5,Dust resistance:IP-6X
CE NBY
MIL-STD-810GY
BatteryUN38.3,MSDS,IEC62133
EnviromentDrop Height1.2m composite wood floors, in operation status
Operate Temperature‘-10 °C to 50 °C
Store Temperature’-20 °C to 60 °C
HumidityHumidity: 95% Non-Condensing
