Digital SignageLumia 355 – 365 Android based industrial monitor

Android based 4K – HD digital signage monitor with native web app, integrated mediaplayer, HTML5 kiosk browser and multi view option.

Fits perfectly any IoT 4.0 Industrial application combining both webbased visualization and multiview presentations.
IP55 full protection with industrial grade components for any harsh industrial enviroment.
Easy configuration software for both remote programming and control.

  • Android 7.1, RK3288 Quad core processor
  • 4K HD industrial LED display
  • Wifi/RJ45/RS232/USB/GPIO/IR ports
  • True flat front tempered glass front
  • IP55 aluminum front and steel back
  • Capacitive touch screen or without touch screen
  • Multi Video input
  • Install and launch apps remotely
  • Operate, update, maintain remotely
  • Develop and launch your own content
  • VESA (400mm) and wall fix

Lumia 355 – 365

Download pdf

  LUMIA 355LUMIA 365
Size1348mm*819mm*105mm(L*W*T)1610mm*1000.4mm*105mm(L*W*T)
ColorFront black, Industrial white back.Front black, Industrial white back.
DisplaySize55inches (LG) 4K industrial LED65inches (LG) 4K industrial LED
Resolution3840*21603840*2160
Display size1209.6 × 680.4 mm1428.48 ×803.52 mm
Brightness500cd/m2500cd/m2
Contrast1900-03-02 12:01:001900-03-02 12:01:00
screen ratio1970-01-01 16:09:001970-01-01 16:09:00
Color16.7M   (8-bit + Hi-FRC) , CIE1931 72%  16.7M   (8-bit + Hi-FRC) , CIE1931 72%
View angle88/88/88/8888/88/88/88
Respond time8 (Typ.)(Tr+Td) (ms)8 (Typ.)(Tr+Td) (ms)
BoardRK3288 Quad core Cortex A17, double channel LVDS, ARM Mali-T764 GPU. TE, ASTC, AFBC memory compression, support 2160P and 4k H.264 HP 1080P@30fps video decoding
1.6 GHz
RAM: 2GB1.6 GHz
Flash: 16GFlash: 16G
1xTF slot1xTF slot
1xGPIO1xGPIO
1xIR1xIR
2xRS2322xRS232
2xUSB 2.02xUSB 2.0
1xRJ451xRJ45
1xHDMI1xHDMI
1xVGA1xVGA
1xWIFI1xWIFI
Android version 7.1Android version 7.1
PCAP55" water proof65" water proof
TypeProjected capacitive touch screenProjected capacitive touch screen
Points10points10points
Transmittance0.950.95
Resolution4096x40964096x4096
Life50000hours50000hours
Touch respond time<=3ms<=3ms
HardnessMohs 7Mohs 7
SoundBuilt-in speakersBuilt-in speakers
Power supply100-240VAC,50/60HZ100-240VAC,50/60HZ
Power190W230W
Working temperature-10℃~65℃-10℃~65℃
Working humidity10%-90%10%-90%
Storage temperature-20°C-60°C-20°C-60°C
IPIP55 frontIP55 front
Main featuresCustomize split screen:support 1-8 view areassupport 1-8 view areas
Multi managementmulti-level and users managemulti-level and users manage
Images formats.jpg, jpeg.bmp,.png,gif..jpg, jpeg.bmp,.png,gif.
Video formats.avi, .mkv,.mov,.mp4,.mpg,.is,.vob,.trp,.flv,.wmv.avi, .mkv,.mov,.mp4,.mpg,.is,.vob,.trp,.flv,.wmv
Audio formats.mp3, .wma, .ogg, .aac, .wav.mp3, .wma, .ogg, .aac, .wav
File formatspdf, word, excel, .pptpdf, word, excel, .ppt
Network3G/4G, wifi, LAN3G/4G, wifi, LAN
On/OffScheduled on/offScheduled on/off
Remote controlVolume and bright remotely controlVolume and bright remotely control
U disksupport U disk import files and picturessupport U disk import files and pictures
