LUMIA7088" Rugged Tablet
Windows and Android

The ESA Lumia 708 rugged tablet product line is ideal for higly mobile indoor or outdoor workers in harsh enviroment conditions.
Thanks to its capacitive multitouch and sunlight viewable display this Android or W10 based device can be used in the field to ensure data is always available when needed.

  • Fully rugged IP65 (Water-Dust resistant), MIL-STD810G (vibration/shock/120 cm drop reistant), Fanless device
  • 8, 10, 12, 14 inch screen Glove touch, Rain Touch, 10 finger&pen touch enabled
  • 9 hours operation battery life with 100% charging in less then 2.5 hours
  • Battery hotswap wich enables NON-STOP working
  • Light weight
  • Power adapter included

LUMIA 708 CH

Download pdf

LUMIA708CH11W00 - LUMIA708CH11WR0 (2D BAR CODE)
Product FormTypeRugged Tablet
Dimension228*145*16.5mm
Weight715g
LCDScreen Size8“
Resolution800*1280
Brightness450Nit
TPTouch PanelMultipoints Capacitive,Glass+Glass,Rigidity: above 7H-Anti-scratch
CameraFront2.0MP
Rear5.0MP
Speakerbuild in Embedded 8Ω/0.8W waterproof speakerx 1
Micbuild in Sensitivity:-42db, output resistance2.2kΩ
BatteryTypebuild in polymer li-ion battery
Capacity3.7V/8500mAh
Endurance8Hrs
CPUTypeIntel Cherrytrail Z8350
Speed1.44Ghz-1.92GHz
RAMLPDDR34GB
DiskEmmc64GB
G_sensorbuild in Gravity acceleration sensor
WIFIWIFI moduleWIFI 802.11(a/b/g/n/ac) Frequency 2.4G+5.8G dual band WIFI intel 3165D2WG
Bluetoothbuild in BT4.2 (BLE) class1 transmission distance:10m
4Gbuild in EC25
LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8
GPSbuild in U-blox NEO-7 Support :GPS; Capture sensitivity: -160 dBm;Cool Start Time:<50second,Hot start time:<28seconds,frequency:0.25 Hz … 10 MHz (configurable)
TF slotExtensive External Memorysupport TF x1 max:128G
USB InterfaceExtend external memory and data transferUSB2.0 x1 (Host)
Earphone JackAudio Output∮3.5mm standard earphone jack x1
DC JackPowerDC 5V 3A 3.5mm Power connector
HDMI Video OutputHDMI 1.4a Type C x1
Docking connectorpogo Pin12pin Pogo Pin x1
Power AdaptorStandardAC100V ~ 240V、50Hz/60Hz output DC 5V/3A
Operating SystemOS versionWindows 10 IoT English
CertificationIP67
CE NB
MIL-STD-810G
BatteryUN38.3,MSDS,IEC62133
Drop Height1.2m
Operate Temperature‘-10 °C to 50 °C
Store Temperature’-30 °C to 70 °C
HumidityHumidity: 95% Non-Condensing

LUMIA 708 QM

Download pdf

LUMIA708QM11A00 - LUMIA708QM11A00 (+2D BAR CODE)
Product FormTypeRugged Tablet
Dimension228*145*16.5mm
Weight715g
LCDScreen Size8“
Resolution800x1280
Brightness450cd/㎡
TPTouch PanelMultipoints Capacitive,Glass+Glass,Rigidity: above 7H-Anti-scratch
CameraFront5.0MP
Rear13MP
Speakerbuild in Embedded 8Ω/0.8W waterproof speakerx 1
Micbuild in Sensitivity:-42db, output resistance2.2kΩ
BatteryTypebuild in polymer li-ion battery
Capacity3.7V/8500mAh
Endurance6Hrs
CPUTypeSnapdragon MSM8953(8core)
Speed2.0GHz
RAMMemory4GB/ LPDDR3
DiskEmmC64GB
Indicator lightbuild in Indicator light of charge, red light will flash when device has low power. red long light when charging, green long light when full power
L-SensorBuilt-inlight Sensor
Compass Built-inCompass Sensor
Gyro SensorBuilt-inGyro Sensor
G_sensorBuilt-inGravity accelleration sensor
WIFIWIFI moduleWIFI 802.11 b/g/n/a/ac frequency 2.4G+5G dual band WIFI,
Bluetoothbuild in BT4.1(BLE)
2G/3G/4G build in CMCC 4M:
LTE B1,B3,B5,B7,B8,B20,B38,B39,B40,B41
WCDMA 1/2/5/8
GSM 2/3/5/8
GPSbuild in support:GPS+Glonass;Capture sensitivity:-140 dBm;Cool Start Time:<50秒,Hot start time:<5秒,GPS frequency:1575.42MHz,Glonass frequency:1602MHZ
TF slotExtensive External Memoryx1 max:128G
USB Interfacestandard USB 2.0x1 、 type C x1(data&charing)
Earphone JackAudio OutputØ3.5mm standard earphone jack
DC JackPowerDC 5V 3A Ø3.5mm Power connector
HDMI Video OutputHDMI 1.4a Type C
Extensive Slotpogo Pin12pin Pogo Pin
Operating SystemOS versionAndroid 9.0 GMS
Certificate SystemIP67
CEY
MIL-STD-810GY
BatteryUN38.3,MSDS,IEC62133
Drop Height1.2m composite wood floors, in operation status
Operate Temperature‘-10 °C to 50 °C
Store Temperature’-20 °C to 60 °C
HumidityHumidity: 95% Non-Condensing
