LUMIA71212,2" Rugged Tablet
Windows

Fully rugged, fanless Android or W10 based tablet with outdoor display.

  • Tablet robusto per ambiente industriale con grado di protezione IP65 e conforme allo standard MIL-STD810G (vibrazioni, shock, caduta dall’altezza di 120 cm), scheda madre fanless.Display 12.2” pollici multitouch (10 punti) utilizzabile sia con il pennino, il dito e la mano guantata.
  • Batteria di lunga durata (circa 8 ore di funzionamento continuato) con tempo di ricarica inferiore alle 2.5 ore.
  • Cambio della batteria a prodotto acceso per garantire la continuità del servizio
  • Leggerissimo (1500g)
  • Alimentatore incluso

LUMIA 712 CH

Download pdf

LUMIA712CH12W00 - LUMIA712CH12WR0 (+ 2D BAR CODE)
Product FormType12.2"
Dimension319.6*216*23.4 mm
Weight1500g
LCDScreen Size12.2"
Resolution1920*1200
Brightness280Nit
TPTouch Panel10 point capacitive,Glass+Glass,Rigidity: 7H above, anti-scratch,
CameraFront2.0MP
Rear5.0MP
SpeakerBuilt-inbuilt-in 8Ω/0.8W water-proof speaker x2
MicBuilt-insensivity:-42db, Output resistance:2.2kΩ
BatteryTypeLithium-ion polymer, removable
Capacity3.7V/12600mAh
Endurance8Hrs
CPUTypeIntel Cherrytrail Z8350
Speed1.44Ghz-1.92GHz
RAMDDR3L4GB
ROM Emmc128GB
G_sensorBuilt-ingravity sensor
WIFIWIFI ModuleWIFI 802.11(a/b/g/n/ac) Frequency 2.4G+5.8G dual band WIFI
BluetoothBuilt-inclass1 transmission distance:10m
4GBuilt-inEC25-EC
LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8
GPSBuilt-inCapture sensitivity: -160 dBm;frequency:0.25 Hz … 10 MHz
TF slotExtensive External MemoryTF x1 max:128G
SIM card slot3G/4G communicationSIM card x1
USB connectorExtensive external memory and data transferUSB 2.0*2 (4pin) Host
USB 3.0*1
MICRO USB connectorUSB2.0 MICRO USB x1
Earphone JackAudio Output∮3.5mm standard earphone jack x1
DC JackPowerDC 5V 3A ∮3.5mm power adaptor x1
HDMI Video OutputHDMI 1.4a x1
Serial port connectorSerial Port DB9 (RS232) ×1 DB9 (RS485) ×1
RJ45 connectorEthernet port10/100Mbps ×1
Extensive connectorpogo Pin12pin Pogo Pin x1
powerOn/Off x1
volumevolume up/volume downvolume+- x2
F KEYScannerCode scanner(back of unit) x1
programProgram KeySelf define key x2
Operation SystemOS versionWindows 10 IOT English;
Certificate SystemIP65IP65
CEY
MIL-STD-810GY
BatteryUN38.3,MSDS,IEC62133
Product ReliabilityDrop Height80cm
Operate Temperature‘-10 °C to 50 °C
Store Temperature’-20 °C to 60 °C
HumidityHumidity: 95% Non-Condensing

Lumia 712 SK

Download pdf

LUMIA712SK22W00 LUMIA712SK22WR0 (+ 2D BAR CODE)
Product FormTypeRugged Tablet
Dimension319,6x216x23,4 mm
Weight1500g
LCDScreen Size12,2"
Resolution1920x1200
Brightness280 cd/m2
TPTouch Panel10 points Capacitive, Glass+Glass, Rigidity: above 7H-Anti-scratch
CameraFront2.0MP
Rear5.0MP
SpeakerBuilt-inEmbedded 8Ω/0.8W waterproof speaker x 1
MicSensitivity:-42db, Output resistance:2.2kΩ
BatteryTypeLithium-ion polymer battery , removable
Capacity7.4V/6300mAh
Endurance6hrs
CPUTypeIntel® Skylake M3-6Y30
Speed2.20 GHz
RAMDDR3L8GB
SSDNGFF SSD128GB
G_sensorBuilt-inGravity acceleration sensor
WIFIWIFI ModuleWIFI 802.11(a/b/g/n/ac) dual frequency 2.4G+5.8G WIFI intel 3165D2WG (3.3v)
BluetoothBuilt-inBT4.2 (BLE) class1 transmited distance:10m
4GBuilt-inEC25-EC
LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8
GPSBuilt-inU-blox NEO-7,Support:GPS; Capture sensitivity:-160 dBm;Cool Start Time:<50 second,Hot start time:<28 second,Frequency:0.25 Hz … 10 MHz (configurable)
TF SlotExtensive External MemorySupport TF x1 max:128G
SIM SlotSIM SlotSIM x1
Micro usbUSB2.0USB 2.0 x1
type A usbUSB3.0USB 3.0 x1
DC JackPowerDC 12V 4A ∮4.0mm Power connector x1
Earphone JackAudio OutputØ3.5mm Standard Earphone Jack x1
HDMI JackAudio&Video OutputHDMI 1.4a Type C x1
Extensive SlotPogo Pin12pin Pogo Pin x1
DB9 PORTSerial portx1 (RS232) TTL Electrical Level
RJ45 PORTEthernet portx1 (10/100 Self-adaption)
Operating SystemOS versionwindows 10 IoT English
Certificate SystemIP65IP65
CEYES
MIL-STD-810GYES
CCCYES
BatteryUN3803,MSDS,IEC62133,Aviation, Ocean shipping reports
Product ReliabilityDrop Height80cm
Operate Temperature‘-10 °C to 50 °C
Store Temperature’-20 °C to 60 °C
HumidityHumidity: 95% Non-Condensing
