Rugged TabletLumia 7xx rugged tablet

Fully rugged, fanless Android or W10 based tablet with outdoor display.

  • Fully rugged IP65 (Water-Dust resistant), MIL-STD810G (vibration/shock/120 cm drop reistant), Fanless device
  • 8, 10, 12, 14 inch screen Glove touch, Rain Touch, 10 finger&pen touch enabled
  • 9 hours operation battery life with 100% charging in less then 2.5 hours
  • Battery hotswap wich enables NON-STOP working
  • Light weight

Lumia 7xx

The ESA Lumia 7xx rugged tablet product line is ideal for higly mobile indoor or outdoor workers in harsh enviroment conditions.

Thanks to its capacitive multitouch and sunlight viewable display this Android or W10 based device can be used in the field to ensure data is always available when needed.

The complete list of accessories available does ensure the complete customization and fitting to the application requirements.

  • Power adapter
  • Charging docking station
  • Vehicle mount holder with integrated charging connection
  • Removable battery
  • Aside and backside handle
  • Removable keyboard

Download pdf

 LUMIA 714LUMIA 712LUMIA 710LUMIA 708
OSWindows 10 Pro/Windows 7 ProWindows 10 ProWindows 10 Pro/Android8.1Windows 10 Pro/Android7.0
LCD14" IPS TFT LCD FHD (1920 x 1080)12.2" IPS TFT LCD FHD (1920 x 1200)10.1" IPS TFT LCD FHD (1280 x 1200)8" IPS TFT LCD FHD (1280 x 800)
1000nit LumiBond® display,sunlight readable700nit LumiBond® display, sunlight readable750nit LumiBond® display, sunlight readable700nit LumiBond® display, sunlight readable
CPUIntel® Core™ i5-6200U 2.3GHz~2.8GHz, Intel® Turbo Boost, 3MB Intel® Smart CacheIntel Atom x5-Z8350 Quad-core 1.42Ghz,Turbo 1.92GHzIntel Atom x5-Z8350 Quad-core 1.42Ghz,Turbo 1.92GHzIntel Atom Cherry-Trail Z8350 Quad-core 1.42Ghz,Turbo 1.92GHz
RAM4GB DDR44GB DDR34GB DDR34GB LPDDR3
SSD64G SSD64G EMMC64G EMMC64G EMMC
Button8 buttonsno buttonsno buttonsno buttons
TouchCapacitive touch screenCapacitive touch screenCapacitive touch screenCapacitive touch screen
Slots1 x SIM card1 x SIM card1 x SIM card1 x SIM card
Micro SD card slotMicro SD card slotMicro SD card slotMicro SD card slot
I/O1 x Audio and micropone1 x Audio and micropone1 x Audio and micropone1 x Audio and micropone
1 x DC in Jack1 x DC in Jack1 x DC in Jack1 x DC in Jack
2 x USB 3.01 x USB 3.01 x Micro USB1 x Micro USB
1 x USB 2.02 x USB 2.01 x USB 2.01 x USB 2.0
1 x HDMI1 x micro HDMI-I1 x HDMI 1.4a1 x micro HDMI
1 x Docking connector 24-pin1 x Docking connector 12-pin1 x Docking connector 12-pin1 x Docking connector 12-pin
1 x Camera 8MP auto focus rear camera1 x Front 2.0M camera, Back 5.0M Camera1 x Front 2.0M camera, Back 5.0M Camera1 x Front 2.0M camera, Back 5.0M Camera
\1 x TF card slot1 x TF card slot1 x TF card slot
\2 x RS232/4851 x RS232no
1 x 10/100/1000 base-T ETH1 x 10/100/1000 base-T ETH1 x 10/100/1000 base-T ETHno
Wifi-Intel® Dual Band Wireless-AC 8260, 802.11acWifi-802.11 a/b/g/n wireless 2.4G/5.0Ghz Dual-bandWifi-802.11 a/b/g/n wireless 2.4G/5.0Ghz Dual-bandWifi-802.11 a/b/g/n wireless 2.4G/5.0Ghz Dual-band
EM7430C4G Network: 4G Frequency: FDD LTE Bands:B1/B3/B5/B7/B8/B20; TDD LTE Bands: B38/B39/B40/B41.4G Network: 4G Frequency: FDD LTE Bands:B1/B3/B5/B7/B8/B20; TDD LTE Bands: B38/B39/B40/B41.4G Network: 4G Frequency: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28 LTE TDD: B40 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8
Bluetooth (v4.2)Bluetooth (v4.2)Bluetooth (v4.2)Bluetooth (v4.2)
SecurityIntel® vPro™nonono
TPM 2.0nonono
Kensington locknonono
Power100-240VAC, 50 / 60Hz, 65W100-240VAC, 50 / 60Hz, 65W100-240VAC, 50 / 60Hz, 65W100-240VAC, 50 / 60Hz, 65W
2x Li-Ion battery 10.8V,3220mAh1x Li-Ion battery 3.7V,12600mAh1x Li-Ion battery 3.7V,10000mAh1x Li-Ion battery 3.7V,7800mAh
LifeSupport™ battery swappable technologyLifeSupport™ battery swappable technologyLifeSupport™ battery swappable technologyLifeSupport™ battery swappable technology
Dimension369 x 248 x 32.5 mm370 x 248 x 32.5 mm280 x 187 x 22 mm225 x 143 x 19 mm
Weight2.3 kg2.3 kg1.2kg0.74kg
RuggedMIL-STD-810G and IP65 certificationMIL-STD-810G and IP65 certification,CEMIL-STD-810G and IP65 certification,CEMIL-STD-810G and IP67 certification,CE
4 inches height break proof1m height break proof1m height break proof1m height break proof
e-Mark car certificationnonono
EnvironmentWorking:-20°C ~ 60°CWorking:-20°C ~ 60°CWorking:-20°C ~ 60°CWorking:-20°C ~ 60°C
Storage:-50°C ~ 70°CStorage:-50°C ~ 70°CStorage:-50°C ~ 70°CStorage:-50°C ~ 70°C
Humidity:95% RH , non-condensingHumidity:95% RH , non-condensingHumidity:95% RH , non-condensingHumidity:95% RH , non-condensing
